The Rotating Telehandlers range allows 360° operation thanks to the rotating turret, which offers a greater range of action compared to a fixed telescopic handler. The new family marks a new era by introducing new standards in the field of telescopic handlers for the construction sector and expanding the product range with new contents, adapting more and more to the needs of different users.
“S Plus-CVTronic” model:
This model represents the top of the range, a true concentration of technology and performance that’s destined to remain a leader in world markets. This is also thanks to the prestigious awards already won by the range.
This new ROTO70.28SPlus-CVTronic model’s main features include: the multi-position stabilisers with automatic control, the advanced safety system, the continuous turret rotation and the new cab with a modular design, equipped with the exclusive tilting system that adapts the tilt up to 20°. This model can be equipped with the award-winning CVTronic (continuously variable transmission) system, which ensures an acceleration from 0 to 40km/h without torque or gear change interruption.
POINTS OF STRENGTH
Everything at your fingertips
Guarantees maximum movement precision, thanks to the hydrostatic transmission, which ensures millimetric variations in the machine’s movements and load’s positioning.
Compact and lightweight:
The Merlo telescopic handlers are compact and lightweight to reduce manoeuvring space and impact on the ground. These features guarantee safety, manoeuvrability, productivity and lower consumption.
Merlo telescopic handlers are designed to offer the best visibility on the market, ensuring faster and safer operations.
The Merlo CVTronic intelligent continuous transmission combines the Merlo experience, acquired on hydrostatic transmissions, with new technical solutions that allow it to reach the same performances, consumption and yields of a traditional CVT transmission.
Rotating Telehandlers Chassis Levelling:
The tilt correction system, integrated into the chassis, is available as standard on this model. It allows the operator to offset the ground slopes to work in total safety. On sloping terrain the operator can correct the lateral inclination by 12% and frontal inclination by 4%. This allows the telescopic boom to be moved out perpendicularly to work in conditions of maximum safety.
The best workplace
Quiet and comfortable:
The new cab, of generous dimensions (1.010 mm), is mounted on Silent Blocks, which drastically reduce vibrations, guaranteeing maximum comfort and maximum visibility for the operator.
Quick accessories changeover:
The Tac-Lock system for hydraulic clamping of the attachments further improves operating comfort.
Protection of the handled load:
The boom suspension system (BSS) is available as an option, which protects the load during transfer and maintains a high level of driving comfort on rough terrain.
Air Conditioning System:
The air flow is distributed homogeneously within the passenger compartment and optimally reaches all areas for first-class comfort.
Travelling in total comfort:
The electronically controlled active suspensions guarantee a more comfortable operation, especially when operating on uneven ground, reducing transport times and increasing operator comfort. The device also operates as a transversal and frontal inclination corrector, allowing you to work in total safety even on sloping terrain.
The exclusive Merlo cab tilting system ensures greater levels of comfort, ergonomics and safety. From the driver’s seat, the operator activates the cab’s tilting feature via the dedicated button. The longitudinal inclination reaches 20° and allows you to monitor the movements of the load when working at a height.
Not just feelings
The Merlo integrated safety system controls the operating parameters in real time, allowing the operator to work in peace.
Certified cabs / Certified protection:
The Merlo cab is FOPS – Level II – and ROPS certified, to guarantee a high level of safety for the operator.
Everything under control:
This model is equipped with the exclusive new generation ASCS (Adaptive Stability Control System) safety system. The ASCS checks the safety parameters of the telescopic handler in real time and allows the operator to work in total safety, making the most of the telescopic handler’s potential and the attachment used.
Simpler and smarter
Simple and precise operations:
The entire range is equipped with hydrostatic transmission, which makes the work phases simpler and more precise. Moreover, the dry disc brakes limit the absorption of energy, thereby reducing the machine’s fuel consumption.
The exclusive Eco Power Drive (EPD) technology automatically controls and adjusts the engine revolutions based on operating conditions. As a result, the engine speed is disconnected from the accelerator pedal. This technology achieves a reduction in fuel consumption of up to 18%.
